Updates



  • 2009June 9

MicroSurvey CAD 2010



Updated CAD Engine - IntelliCAD 6.6

MicroSurvey CAD 2010 is now built on the latest IntelliCAD engine, IntelliCAD 6.6. For a list of IntelliCAD fixes, see below.

Learn More

MicroSurvey CAD 2010 is now built on the latest IntelliCAD engine, IntelliCAD 6.6. For a list of IntelliCAD fixes, see below.

Pad Builder

New command: _BUILD_PAD (MsTools | Pad Builder)

Learn More

Draw and edit pads directly within your current drawing by specifying edge lengths, turned angles, deflection angles, or double-offsets. This is different than the previously existing House Library commands which creates drawings in an external house library.
New command: _BUILD_PAD (MsTools | Pad Builder)

Offset Grid Lines

New command: _MS_OFFSET (MsTools | Offset Grid Lines)

Learn More

Easily offset Lines in your drawing by varying offset distances. This is similar to the existing _PARALLEL or _OFFSET command but is easier to use.
New command: _MS_OFFSET (MsTools | Offset Grid Lines)

Auto-Add Points to Gridline Intersections

New command: _COORDINATE_GRID_LINES (MsTools | Coordinate Grid Lines)

Learn More

Automatically compute points at the 3D intersection of selected Lines in your drawing. This is intended primarily for calculating points on grid lines, but it can be used in many situations.
New command: _COORDINATE_GRID_LINES (MsTools | Coordinate Grid Lines)

Query Angle between Two Lines

New command: _MS_SHOW_ANGLE (MsCogo | 3-Point Inverse)

Learn More

Calculates a 3-point inverse to determine the interior or exterior angle between two lines, and displayes the angle to you in both decimal degrees and degrees-minutes-seconds.
New command: _MS_SHOW_ANGLE (MsCogo | 3-Point Inverse)

Point Patterns

New command: _POINT_PATTERN (MsTools | Point Patterns)

Learn More

Create a custom library of point patterns to use for calculating multiple points in relation to other key points in your drawing. This is used primarily for applying Bolt Patterns onto columns, beams, etc.
New command: _POINT_PATTERN (MsTools | Point Patterns)

Online Update Notification

MicroSurvey CAD now includes a "Check for Updates" feature. This new command is available in the Help Menu.

Learn More

MicroSurvey CAD now includes a "Check for Updates" feature. This new command is available in the Help Menu.
MicroSurvey CAD is now configured to silently look for updates according to the preferences setup by the user. When an update is available the user will be notified. Updates are automatically downloaded and installed.
New command: _UPDATECHECK (Help | Check For Updates)
New command: _UPDATECHECK_CFG (Help | Auto Update Preferences)

Layer States

New command: _LAYERSTATE (MsTools | Layer Control | Layer States)

Learn More

Save and Restore Layer States in your drawing. A layer state contains a snapshot of the state of all layers in your drawing (including: On/Off, Frozen/Thawed, Locked/Unlocked, Color, Linetype, Lineweight) at that point in time, so that when loaded all of these layer settings get restored to the state they were in when that layer state was saved.
If the layer state file is imported into a new drawing, it will automatically create the layers that are missing.
New command: _LAYERSTATE (MsTools | Layer Control | Layer States)

Normalize Raw Traverse Measurements

Improved command: _MS_EDIT_RAW_DATA (MsTraverse | Active Traverse Editor)

Learn More

A new command is now available in the Active Traverse Editor, which will normalize Face 2 total station measurements to Face 1. This is necessary for users who want to perform a 3D Least Squares Adjustment.
Improved command: _MS_EDIT_RAW_DATA (MsTraverse | Active Traverse Editor)

Improved Stakeout

More intuitive dialog layout and workflow.

Learn More

More intuitive dialog layout and workflow.
You can now specify any description for the computed stake points instead of the previous "FSTAKE" description.
You can now specify zero offset distances to compute stake points directly on the line/arc.
As each new stake point is computed, if a point already exists at the same position then you are now prompted for whether you to store the new point or not.
Improved command: _COMPUTE_STAKES (MsPoints | Stake Out Points)

Improved Auto-Add Points to Objects

Now works with Polylines, LWPolylines, and 3DPolylines.

Learn More

Now works with Polylines, LWPolylines, and 3DPolylines.
Improved command: _AUTOP (MsPoints | Auto-Add Points to Objects)

Improved Mapping Grid

Improved scaling of labels and "+" grid marks, and preview capabilities.

Learn More

Improved scaling of labels and "+" grid marks, and preview capabilities.
New preview capabilities so you can see the grid before placing it in your drawing.
Grid is now drawn onto a dedicated "MAPPING_GRID" layer (instead of the current layer).
Improved command: _MAPPING_GRID (MsTools | Mapping Grid)

Improved Star*Net Exporter

We have made several improvements to the star*net exporter, which allows traverses from MicroSurvey CAD to be adjusted in star*net more easily, including the following:

Learn More

We have made several improvements to the star*net exporter, which allows traverses from MicroSurvey CAD to be adjusted in star*net more easily, including the following:
Units and Order records are now added to header section.
Date Processed note recorded in the header section.
Directory and traverse file that the export is based on is recorded as a note in the header section.
We do not record a C record for every setup anymore, only for the inital setup points.
FieldGenius Multiset backsight measurements are now exported as DV records.
FieldGenius Multiset foresight measurements are now exported as M records.
Angle format in the DAT file now uses the Starnet notation of degress-minutes-seconds. For example angles will look like: 90-00-34.55 instead of 90.003455
Distances are now displayed in the DAT file to four decimal places.
Undefined distances in DV and M records are now exported as ? instead of 0.0000.
Fixed odd behaviour when selecting the DAT file export directory. It would always default to C:\Star
Exported DAT file is automatically opened in Notepad after export for review.
Now available in MicroSurvey CAD Basic, Standard, and Premium versions. (Previously Standard and Premium only)
Improved command: _STAR_NET_EXPORT (MsTraverse | Star Net Interface)

  • 2009Dec 3

MicroSurvey CAD 2009



New CAD Engine

IntelliCAD 6.5 Engine
MicroSurvey CAD 2009 is now built on the latest IntelliCAD engine, IntelliCAD 6.5.

Learn More

IntelliCAD 6.5 Engine
MicroSurvey CAD 2009 is now built on the latest IntelliCAD engine, IntelliCAD 6.5.
Performance enhancements
Performance has been enhanced considerably when using real-time zoom, real-time pan, and saving drawings.
Toolbar and menu icons
The IntelliCAD user interface has been enhanced with new 24-bit icons for all color toolbar icons and menus.
Use polar tracking
Polar tracking is a new tool used to help you draw with precision. When polar tracking is turned on, guides display on the screen automatically at specified polar angle increments.
Check the spelling of text
You can check the spelling of single-line text, multiline text, paragraph text, attributes, attribute definitions, and dimension text. Additional features include loading dictionaries from different sources, including various languages, and adding your own words to a custom dictionary.
Copy multiple entities
Now it’s easier to copy multiple entities. IntelliCAD defaults to prompting for additional copies of selected entities during the Copy command.
Work with additional image formats
The number of image formats available for drawings has been expanded. You can include images in the following formats: ECW, JPG 2000, ERS, ALG, HDR, DAT, DOQ, FST, NTF, ASC, IMG, DEM, DDF, DT0 and DT1, and HDF (including MET, L1R, and L1G).
Layer toolbar
You can now use the Layer toolbar to specify layout-specific layer settings. The Layer toolbar dynamically sizes, making it easier to manage large layer lists or drawings with long layer names.
Customize the status bar and menus using DIESEL
You can use DIESEL from the command line, in MNU menu files, and in LISP to customize the status bar and menus.
Use new and enhanced system variables
New or enhanced system variables include: AUTOSNAP, COPYMODE, DCTCUST, DCTMAIN, DCTMAINPATH, DIMTFAC, POLARADDANG, POLARANG, POLARDIST, POLARMODE, SNAPTYPE, and TRACKPATH.

Active Coordinate Editor

Dropbox, Microsoft OneDrive, Google Drive, and other cloud storage and synchronization services are now supported.

Learn More

Multiple Coordinate Systems
The Active Coordinate Editor can be configured to display your point coordinates as transformed into up to 2 cartesian systems and 2 geodetic system.
Draw Coordinate Tables
Create coordinate tables and/or coordinate conversion tables in your drawing by selecting the columns and rows you want to include from the Active Coordinate Editor.

Input/Output Scale Factors

Inverse between Input Scale Factor and Output Scale Factor
The Input Scale Factor and Output Scale Factor fields on the General Configuration Options screen have been linked together, so you can now automatically set one as the inverse of the other with the press of a button.

Learn More

Input Scale Factor works with All Commands
The Input Scale Factor specified in the General Configuration Options screen can now be applied to ALL distance inputs in the program, by specifying an "s" (for scale) suffix after the distance, for example 100s or 100S. Scaling was previously limited to only the MicroSurvey commands, but now also works with all CAD drawing, modification, and settings commands. Use the s suffix anywhere you can enter distances, including at the command line, in dialog boxes, and even when typing coordinate values like "100s,100s".
Inverse between Input Scale Factor and Output Scale Factor
The Input Scale Factor and Output Scale Factor fields on the General Configuration Options screen have been linked together, so you can now automatically set one as the inverse of the other with the press of a button.
Copy Output Scale Factor to Distance Labeling Scale Factors
A new Scale Factors dialog lets you easily configure all scale factors (Input Scale factor, Output Scale Factor, and five Distance Labeling Scale Factors) in one screen with no calculations required.
Automatic Blunder Detection
When your Input Scale Factor and Output Scale Factor values are not inverses of each other, or when the Output Scale Factor does not match your Distance Labeling Scale Factors, warning will appear to help you correct any potential issues.
Scale Factor Check on FieldGenius/RAW/RW5 File Import
When importing a RAW or RW5 file (including FieldGenius projects), the scale factors specified in the RAW file and in the General Configuration Options screen will be compared as a validation check, and if they do not match a Scale Factor dialog (see above) appears to help you correct any potential issues.
Scale Factor Setup on FieldGenius Export
When exporting a FieldGenius Project, a new option is available which will write the scale factor to the new project's raw file.
LISP Programming Extensions
Four new Lisp routines are available for your custom programming needs. New commands: (get_output_scale_factor), (set_output_scale_factor x), (get_input_scale_factor), (set_input_scale_factor x).

Geodetic Coordinate Conversions

Remember Last Used Coordinate Systems
When selecting coordinate systems, the last used system will be remembered as a default and automatically selected again the next time you use the same command.

Learn More

Remember Last Used Coordinate Systems
When selecting coordinate systems, the last used system will be remembered as a default and automatically selected again the next time you use the same command.
Recently Used Coordinate Systems
When selecting coordinate systems, a list of your most recently used systems is available for quickly selecting your typical settings.

LandXML Import/Export

XML Import
A new XML Import command allows you to select any LandXML file to import the following data types from it: CgPoints (as Point Coordinates), PlanFeatures (as Smart Lines/Arcs), Parcels (as Lots), and Surfaces. New command: _LANDXML_IN

Learn More

XML Import
A new XML Import command allows you to select any LandXML file to import the following data types from it: CgPoints (as Point Coordinates), PlanFeatures (as Smart Lines/Arcs), Parcels (as Lots), and Surfaces. New command: _LANDXML_IN
XML Export
A new XML Export command allows you to write a LandXML file containing the following data types from your drawing: Point Coordinates (as CgPoints), Smart Lines/Arcs (as PlanFeatures), Lots and Blocks (as Parcels), Surfaces (as Surfaces). New commands: _LANDXML_OUT and _LANDXML_OUT_RANGE
A new XML Export command allows you to write a LandXML file containing the following data types from your drawing: Point Coordinates (as CgPoints), Alignments (as Alignments). New command: _WRITEXML

3D Polyline Utilities

Insert Vertex
Insert one or more consecutive vertices in a 3D Polyline by selecting two adjacent vertices, such that new vertices will be inserted evenly between them with their elevations adjusted to fit a linear interpolation. New command: PEDIT_RI

Learn More

Insert Vertex
Insert one or more consecutive vertices in a 3D Polyline by selecting two adjacent vertices, such that new vertices will be inserted evenly between them with their elevations adjusted to fit a linear interpolation. New command: PEDIT_RI
Delete Vertex
Delete one or more consecutive vertices in a 3D Polyline by selecting two vertices, such that all vertices between them will be removed. New command: _PEDIT_RD
Interpolate Vertex
Interpolate one or more consecutive vertices in a 3D Polyline by selecting two vertices, such that all vertices between them will have their elevations adjusted to fit a linear interpolation. New command: PEDIT_RZ

Lot Closures & Plan Check

Pick Text Labels for Lot Closures / Plan Check
Check your plan by using the new "Pick" buttons on the Lot Closure dialog, to select line and curve labels for calculating a closure based on the text labels.

Learn More

Pick Text Labels for Lot Closures / Plan Check
Check your plan by using the new "Pick" buttons on the Lot Closure dialog, to select line and curve labels for calculating a closure based on the text labels.
Delete Lot Closures
A command is now available in the MsTools menu to delete existing Lot Closures from your drawing and database. New command: _MS_DEL_LOT_CLOSURE
Lot Closure Dialog Improvements
The Lot Closure dialog was cleaned up and made easier to use. Specifically...
The current entry field is now highlighted by a green box. This helps speed up keyboard entry when defining lots.
All data fields now immediately appear after selecting "Line" or "Curve", previously you were required to press Enter to make the next option appear which was not intuitive.
"Pick" buttons were added beside each distance and direction field, which allow you to select a text entity from your drawing to use for the lot definition.
"Pick All" buttons were added beside the Line and Arc fields, which allow you to select multiple text entities from your drawing to use for the lot definition.
"Swap" buttons were added beside each direction field, to reverse the direction of the currently displayed angle.
Removed Bearing/Azimuth and Feet/Metric controls, in favor of using the drawing's units settings as defined in the General Configuration Options dialog.
Removed OK buttons, in favour of having all fields immediately visible on the dialog.
Removed NW, NE, SW, SE quadrant bearing buttons, which which users found confusing and unnecessary.
Removed Zoom/Pan controls, which were previously necessary for older CAD engines, in favour of using real-time pan and zoom from your mouse.
Removed Current Coordinate text, which users found confusing and unnecessary. Current position is still indicated by an arrow icon in the drawing.
Realigned similar options to make the dialog more intuitive.

AutoRoute/Roading

Spiral Curves
Horizontal Alignments can now be created with Curve-Spiral and Spiral-only curves. (This is in addition to the existing Spiral-Curve and Spiral-Curve-Spiral curves.)

Learn More

Spiral Curves
Horizontal Alignments can now be created with Curve-Spiral and Spiral-only curves. (This is in addition to the existing Spiral-Curve and Spiral-Curve-Spiral curves.)
Road Templates by Grade
The Template Editor now allows for input of Grade values for each zone. (This is in addition to the previously required Height values).

Sewers

Complete Overhaul
There were so many fixes to the sewers commands, that it is practically a new feature. Sewers routines have not worked reliably for several versions.

Learn More

Complete Overhaul
There were so many fixes to the sewers commands, that it is practically a new feature. Sewers routines have not worked reliably for several versions.
Network Layout Updates
Sewer networks are now updated automatically when a structure is deleted, to keep the lines flowing past the deleted structure.
Sewer Browser Command
Our new Sewer Browser command lets you easily work with multiple network layouts. New command: _SEWERBROWSE
Query Structure Command
Our new Query Structure command lets you see information about any structures in your network. New command: _QUERYSTRC

Traverse Data

Show Traverse Graphically
A new option in the Show Traverse command now allows lines to be drawn showing SK stake records.

Learn More

Show Traverse Graphically
A new option in the Show Traverse command now allows lines to be drawn showing SK stake records.
Detect Invalid Records on Import
When importing a RAW or RW5 file (including FieldGenius projects), each line is verified that it contains the correct number of data fields. This is because importing some RAW files which contained invalid records could cause a crash (ie, LS records containing an HR but not an HI).
Detect Current RAW File on Import
When importing FieldGenius projects containing multiple RAW files, the FieldGenius project's INI file is checked to detect the current raw file, and that is set as the current Traverse after import.

Quick Posts & Symbol Librarian

New Survey Libraries
Two new Automap Libraries, Survey-M1 (Metric) and Survey-I1 (Imperial) have been provided which include an improved description list and an improved default layering structure.

Learn More

New Survey Libraries
Two new Automap Libraries, Survey-M1 (Metric) and Survey-I1 (Imperial) have been provided which include an improved description list and an improved default layering structure.
Quick Posts with Wipeouts
New Quick Post blocks are included which use Wipeouts instead of a Trimming Radius to hide details behind/inside the blocks. You must load the new MSCAD_WIPEOUT.CSV AutoMAP Library instead of the default MSCAD.CSV AutoMAP Library to use the wipeout versions of the Quick Posts.
Symbol Librarian Posts with Wipeouts
New Symbol Library blocks are included which use Wipeouts to hide details behind/inside the blocks.
Misc Improvements
The ICI_AI and ICM_AI blocks (and their wipeout-version counterparts) were modified to remove extraneous points that were contained in the blocks.

Updated Interface

Toolbar and menu icons
To match the updated IntelliCAD 6.5 interface, all of the MicroSurvey icons have also been improved to 24-bit color.

Learn More

Toolbar and menu icons
To match the updated IntelliCAD 6.5 interface, all of the MicroSurvey icons have also been improved to 24-bit color.
Digitizer Tablet Support
Updated digitizer tablet overlay and configuration setup files have been created, please see the Tablet Setup topic in the help file.

  • 2005May 1

MicroSurvey CAD 2005



Windows Programming Enhancements
By far the easiest MicroSurvey version to edit and create toolbars, modify menus, and customize your drawing screen, faster zooming, more powerful printing options.

CAD Engine Improvements
Splines with linetypes, Geo-referenced TIFF support, Print Styles, Multiple Layout pages

Drafting Improvements
New labeling options, coordinate table, point update command, more type or pick options

Pricing Packages
Cost effective for every user

Improved Field to Finish
New options in the AutoMap system make it easier to process your field files.

Industry Compatibility
DWG, Custom Linetypes, SHX, Lisp Programming, DCL support, MNU support

Product Feature Comparison
The features of MSCAD 2005 Standard version versus Basic and Premium.

X
